4WD and AWD both drive all four wheels. They differ in two ways that matter: whether front and rear can turn at different speeds (so the system can stay engaged on dry pavement), and whether a low-range gear set is available for slow, steep or technical ground. Badges don't tell you either one. The spec sheet does.
At a Glance
| System type | Can stay engaged on dry pavement? | Low range? | Example |
|---|---|---|---|
| Part-time 4WD | No, only on loose or slippery surfaces | Yes | Jeep Command-Trac (2.72:1) |
| Full-time 4WD | Yes | Yes | Jeep Selec-Trac (2.72:1), full-time Rock-Trac (4.0:1) |
| Full-time AWD | Yes | No | Subaru Symmetrical AWD, Jeep Quadra-Trac I |
| On-demand (part-time) AWD | Yes | Usually no | Front- or rear-drive until sensors detect slip |
| AWD-type system with a low range | Yes | Yes | Jeep Active Drive Low (Compass Trailhawk) |
How Part-Time and Full-Time 4WD Work
A part-time 4WD system runs in two-wheel drive by default. Jeep explains that it has no center differential: in 4WD it locks the front and rear driveshafts together so both turn at the same speed. That gives strong traction off-road, but on a dry road the front and rear axles travel different distances in every turn. Because they're locked together, the tires have to scrub. Jeep calls the result crow hop: a bang, a shudder and tire scuffing, which can lead to early part failure. Ford's owner's manuals say the same thing: don't use 4H or 4L on dry, hard-surfaced roads.
Full-time 4WD adds a clutch or a center differential so front and rear can turn at different speeds. It can stay in four-wheel drive on any surface. Jeep's full-time Selec-Trac case, for example, has a 4WD Auto mode as well as 4H and 4L.
How AWD Works
Subaru describes two kinds of AWD. Full-time systems send some power to both axles at all times and use sensors to vary the split. Part-time or on-demand systems drive only the front or rear axle until sensors detect slip, then bring in the other axle. Neither asks the driver to do anything. Jeep's Quadra-Trac I on the Grand Cherokee is an always-engaged system of this kind, paired with a brake lock differential. Jeep notes it has no low range.
What Low Range Adds, in Numbers
Low range is a reduction gear in the transfer case that multiplies torque and slows the wheels. The combined effect shows up as the crawl ratio: first gear × low range × axle ratio. The higher the number, the slower and more controlled the vehicle can creep at idle.
| Vehicle and system | Low range | Crawl ratio |
|---|---|---|
| Ford Bronco Sport (4x4 with power transfer unit and rear drive unit) | No two-speed transfer case | 18:1 |
| Jeep Compass Trailhawk (Active Drive Low) | Yes | 20:1 |
| Jeep Wrangler Sport, automatic, 3.45 axles (Command-Trac) | 2.72:1 | about 44:1 (calculated) |
| Jeep Wrangler Rubicon, automatic, 4.10 axles (Rock-Trac) | 4.0:1 | about 77:1 (calculated) |
| Jeep Wrangler, maximum as equipped | 4.0:1 | up to 100:1 (Jeep claim) |
The Bronco Sport carries a 4x4 badge, but Ford's spec sheet describes a power transfer unit feeding a rear drive unit, with no two-speed case. Its crawl ratio comes from the transmission and final drive alone. The Compass Trailhawk is a crossover too, but Jeep's Active Drive Low adds a low range. The badge on the tailgate tells you neither.
How to Tell What a Vehicle Actually Has
- Look for a low-range ratio or a crawl ratio in the manufacturer's specification sheet. A two-speed transfer case lists one, for example "Low Range Ratio 2.72:1."
- Check the transfer case type: part-time or full-time, and the operating modes (2WD High, 4WD Auto, 4WD High, Neutral, 4WD Low).
- Read the owner's manual's 4WD section. If it tells you not to use 4H on dry pavement, the system is part-time.
Which One a Given Vehicle Needs
For paved roads in rain and snow, AWD or full-time 4WD handles the job without driver input. Tires set the limit on snow and ice; Subaru recommends snow tires whichever system you have. Low range earns its place when you need slow, controlled movement: Jeep lists steep climbs, getting out of a tough spot, rock crawling and pulling a boat trailer out of the water. If a vehicle will regularly see that kind of use, confirm a low range and a crawl ratio on the spec sheet before buying. See 4 high vs 4 low for how the two ranges are used, and when to use 4WD once you have one.
