TL;DR
- IIHS dates the two recent F-150 generations to redesigns for 2015 and 2021; Ford updated the current truck again for 2024.
- For 2026, 4x4 XL, STX and XLT trucks use a part-time shift-on-the-fly case, Lariat, King Ranch and Platinum get Ford's Torque On Demand automatic case, and Tremor and Raptor get an automatic case with a mechanical 4WD lock.
- The Raptor's factory tires are 35 inches (37 with the 37 Package) and its ground clearance tops out at 13.1 inches; most other 4x4 F-150s sit at 9.8 inches.
- Maximum towing for 2026 is 13,500 lb (3.5L EcoBoost, SuperCrew, Max Tow) and maximum 4x4 payload is 2,175 lb.
- The large April 2026 recall is real: NHTSA 26V237 covers 1,392,935 F-150s from 2015–2017 that can unexpectedly downshift into second gear.
At a Glance
| If your 2026 F-150 is a… | What its 4x4 does | Good fit for |
|---|---|---|
| XL, STX or XLT 4x4 | Part-time 4WD you switch on and off; high and low range | Work sites, snow, dirt roads |
| Lariat, King Ranch or Platinum 4x4 | Adds an automatic mode that sends power to the front axle when needed | Mixed wet, snowy and dry roads |
| Tremor | Automatic 4WD plus a mechanical lock, 275/70R18 all-terrain tires, 10.7 in of clearance | Trails on a full-size pickup |
| Raptor | Same case as Tremor, long-travel FOX suspension, 35- or 37-inch tires | Desert running and rough, fast trails |
Generations and Model Years
IIHS notes that the F-150 was redesigned for the 2015 model year, with its crash ratings for that structure applying to 2015–2020 trucks, and redesigned again for 2021, with ratings covering 2021–2026. Ford's 2020 specifications describe the outgoing truck as a high-strength steel frame with an aluminum cab and bed; the 2021 and 2026 sheets describe a fully boxed high-strength steel frame with a military-grade aluminum-alloy body. Ford introduced the updated 2024 F-150 within the current generation.
The 2026 trims are XL, STX, XLT, Lariat, Tremor, King Ranch, Platinum and Raptor, built at Dearborn Truck Plant and Kansas City Assembly Plant. Every non-Raptor F-150 uses a solid rear axle on leaf springs; the Raptor switches to a five-link coil-spring rear with a Panhard rod.
4WD System by Trim
| Trims (2026) | Transfer case | Differentials | Factory tire (4x4) |
|---|---|---|---|
| XL, STX, XLT | Electronic shift-on-the-fly, 2-speed part-time | Open rear standard; electronic-locking rear optional (per Ford's 2021 sheet) | 265/70R17 A/T (XL), 275/65R18 A/T (STX, XLT) |
| Lariat, King Ranch, Platinum | Torque On Demand 2-speed automatic 4WD | Open rear standard; electronic-locking rear optional (per Ford's 2021 sheet) | 275/65R18 A/T (Lariat), 275/60R20 A/T (King Ranch, Platinum) |
| Tremor (and STX Lobo) | 2-speed automatic AWD with mechanical-locking 4WD and Hi-Lock | Electronic-locking rear | 275/70R18 A/T (Tremor) |
| Raptor, Raptor R | 2-speed automatic AWD with mechanical-locking 4WD and Hi-Lock | Electronic-locking rear, 4.10 axle | LT315/70R17 A/T; 37x12.5R17 with 37 Package |
A part-time case drives both axles only when the driver selects 4H or 4L. Ford's Torque On Demand case adds an automatic setting that manages front-axle engagement on its own. The Hi-Lock case on Tremor and Raptor can run in automatic AWD or lock mechanically into 4WD. None of the 2026 spec sheets lists a front locker for any F-150: Ford's 2021 specifications offered a Torsen (torque-sensing) front differential as an option on Tremor, and the 2024 Raptor sheet lists only the electronic-locking rear. Ford's 2026 sheet pairs the PowerBoost hybrid 4x4 with the electronic-locking rear.
On the 2015–2020 truck, Ford's 2020 specifications list an electronically controlled 4x4 with an optional electronic-locking differential across XL, XLT, Lariat, King Ranch, Platinum and Limited.
Engines, Towing and Payload (2026)
| Engine | Output | Max towing (4x4) | Max payload (4x4) |
|---|---|---|---|
| 2.7L EcoBoost V6 | 325 hp, 400 lb-ft | 8,200 lb | 1,715 lb |
| 5.0L V8 | 400 hp, 410 lb-ft | 12,800 lb | 2,080 lb |
| 3.5L EcoBoost V6 | 400 hp, 500 lb-ft | 13,500 lb | 2,175 lb |
| 3.5L PowerBoost hybrid V6 | 430 hp, 570 lb-ft | 11,600 lb | 1,740 lb |
| 3.5L EcoBoost High-Output (Raptor) | 450 hp, 510 lb-ft | 8,200 lb | about 1,400 lb |
| 5.2L supercharged V8 (Raptor R) | 720 hp, 640 lb-ft | 8,700 lb | about 1,400 lb |
Every 2026 F-150 uses a 10-speed automatic. The highest towing figures need a SuperCrew with the Max Tow/Haul Package and the Max Tow axle upgrade, and Ford notes that payload and towing peaks can't be reached at the same time. The door-jamb label gives the payload of a specific truck. The two Raptor engines call for 91-octane premium; the others are rated on 87.
Ground clearance on 4x4 trucks is 9.8 inches for Regular Cab, SuperCab and the 5.5-foot SuperCrew, 8.8 inches for the 6.5-foot SuperCrew, 10.7 inches for Tremor, and 11.9 or 13.1 inches for the Raptor on 35- or 37-inch tires. Ford lists approach angles of 25.9° for a 4x4 SuperCrew, 27.6° for Tremor and up to 33.1° for a Raptor on 37s.
Cab and Bed Configurations: What Changes for Fitment
| Cab | Bed lengths | Wheelbase | Seats |
|---|---|---|---|
| Regular Cab | 6.5 ft or 8 ft | 122.8 in or 141.5 in | 3 |
| SuperCab | 6.5 ft | 145.4 in | 5 or 6 |
| SuperCrew | 5.5 ft or 6.5 ft | 145.4 in or 157.2 in | 5 or 6 |
| Tremor, Raptor | 5.5 ft SuperCrew only | 145.6 in / 145.4 in | — |
Tonneau covers, bed liners and bed racks are sized by bed: Ford lists inside floor lengths of 67.1 inches (5.5 ft), 78.9 inches (6.5 ft) and 97.6 inches (8 ft), with 50.6 inches between the wheelhouses on all three. SuperCab rear legroom is 33.5 inches against 43.6 inches in a SuperCrew, so rear seat covers and floor liners are cab-specific. The Raptor's track is about 74 inches, roughly six inches wider than other F-150s, which is why Raptor bumpers, flares and wheels are separate part numbers. Across generations, the 2015–2020 and 2021-on trucks had different body panels and interiors, so check the model-year range on any bumper, grille, seat cover or mat.
Recall History (NHTSA)
For 2015–2026 F-150s, NHTSA's database lists 102 vehicle recall campaigns as of September 2026, including many shared with other Ford lines. The largest ones that name the F-150 alone:
| NHTSA campaign | Filed | Model years | Problem | Units |
|---|---|---|---|---|
| 18V568 | Aug 2018 | 2015–2018 Regular Cab, SuperCrew | Sparks from a deploying seat-belt pretensioner can ignite B-pillar material | 1,619,112 |
| 26V237 | Apr 2026 | 2015–2017 | Lost signal from the transmission range sensor can force an unexpected downshift into second gear; fix is a PCM software update | 1,392,935 |
| 23V509 | Jul 2023 | 2021–2023, single exhaust | Wiring rubbed by the rear axle housing can apply the electric parking brake while driving | 870,701 |
| 22V842 | Nov 2022 | 2021–2022 | Windshield wiper motor can stop working | 483,082 |
| 20V332 | Jun 2020 | 2014–2017, 3.5L EcoBoost | Brake master cylinder can leak fluid into the booster | 292,311 |
| 26V578 | Sep 2026 | 2023–2027 | Fuel tank may be improperly secured, leak or detach | 223,472 |
| 21V986 | Dec 2021 | 2021–2022 | Loose heat shields can damage the aluminum driveshaft until it fractures | 184,698 |
Shared campaigns worth knowing if you tow: 26V104 (4,381,878 vehicles, including 2021–2026 F-150s) covers an integrated trailer module that can lose communication and drop trailer lights or trailer brakes. 17V652 (1,101,107 vehicles, 2015–2017 F-150 and 2017 Super Duty) covers door latches that can freeze or have a kinked cable, letting a door open while driving. Owners of 26V237 trucks were notified by letter in July 2026. Look up a VIN on NHTSA's site to see a specific truck's open campaigns.
