TL;DR
- The Frontier got an all-new design for 2022 but kept the previous truck's 126.0-inch wheelbase and chassis; it is built in Canton, Mississippi.
- Frontier PRO-4X adds a locking rear differential, Bilstein shocks, skid plates and 265/70R17 all-terrains, with a 2.717:1 low range.
- Frontier bed floors are 59.5 inches (5-foot) or 73.3 inches (6-foot), so bed parts are length-specific.
- Nissan ended Titan and Titan XD production with the 2024 model year; no Titan parts interchange with the Frontier.
- Maximum towing: 7,150 lbs for the 2027 Frontier, 9,290 lbs for the 2024 Titan and 11,050 lbs for the Titan XD with a gooseneck.
At a Glance
| Frontier (2027) | Titan (2024, final year) | |
|---|---|---|
| Size | Midsize | Full-size |
| Engine | 3.8-liter V6, 310 hp, 9-speed automatic | 5.6-liter V8, 400 hp, 9-speed automatic |
| Wheelbase | 126.0 or 139.8 in | 139.8 in (Titan XD 151.6 in) |
| PRO-4X tire | 265/70R17 all-terrain | 275/70R18 all-terrain |
| Max towing | 7,150 lbs | 9,290 lbs (Titan XD 11,050 lbs with gooseneck) |
Frontier: Generations and What Carried Over
Nissan's 2022 press kit describes an all-new design for the Frontier, but says the truck kept the previous model's 126.0-inch wheelbase and its chassis. The 3.8-liter V6 (310 hp, 281 lb-ft) and 9-speed automatic arrived before the new body: Nissan says the 9-speed was all-new for 2020. So a 2020–2021 Frontier has the current powertrain in the older body, while 2022-and-later trucks have the new body on the carried-over chassis. For drivetrain parts, match the powertrain; for bumpers, grilles, lighting and bed parts, match the body year.
Frontier Cabs, Beds and Wheelbases
Nissan's 2027 Frontier press kit lists four grades (S, SV, PRO-X and PRO-4X), a King Cab on the S grade and a Crew Cab on every grade, with 5-foot and 6-foot beds.
| Configuration | Wheelbase | Overall length | Bed floor length |
|---|---|---|---|
| King Cab | 126.0 in | — | 73.3 in (6-ft bed) |
| Crew Cab, short bed | 126.0 in | 210.2 in | 59.5 in (5-ft bed) |
| Crew Cab, long bed | 139.8 in | 224.1 in | 73.3 in (6-ft bed) |
Tonneau covers, bed racks and bedliners are sold by bed length, and sliders and side steps by cab and wheelbase, so a 5-foot Crew Cab and a 6-foot Crew Cab take different parts even in the same year. A spray-in bedliner trims the 6-foot floor to 72.7 inches, per Nissan.
Frontier PRO-4X: The Factory Off-Road Package
Nissan lists these on the PRO-4X: a part-time four-wheel-drive system with a two-speed transfer case (1.00:1 high, 2.717:1 low), an electronic locking rear differential, Bilstein off-road shocks, aluminum skid plates and 265/70R17 all-terrain tires. In 2022 the kit described one front aluminum and three steel underbody skid plates. Because the PRO-4X already has the rear locker and skid plates, check what an aftermarket part replaces before buying it. Its larger factory tire is also the baseline for any further tire upsize; see all-terrain and mud tires.
Frontier Towing and Payload
For 2027, Nissan's highest Frontier ratings are 7,150 lbs of towing and 1,590 lbs of payload, both on the S King Cab 4x2. A PRO-4X Crew Cab 4x4 is rated at 6,270 to 6,310 lbs depending on wheelbase. Those ratings fall as options and accessories add weight, so steel bumpers, a winch, a roof rack and a bed rack all come out of the payload on the door-jamb label. See towing and payload for the hitch and tongue-weight math.
Titan: A Discontinued Full-Size Truck
Nissan's Titan page says 2024 marked the final year of production for the Titan and Titan XD. Its 2024 press kit lists a 5.6-liter Endurance V8 with 400 hp and 413 lb-ft, a 9-speed automatic, and rear-wheel drive or part-time 4WD with a 2.717:1 low range, the same low-range ratio as the Frontier.
| Configuration | Wheelbase | Bed length |
|---|---|---|
| Titan King Cab | 139.8 in | 78.7 in |
| Titan Crew Cab | 139.8 in | 67.0 in |
| Titan XD Crew Cab | 151.6 in | 78.7 in |
The standard Titan is rated at up to 9,290 lbs of towing and 1,710 lbs of payload; the Titan XD at 11,050 lbs with a gooseneck hitch and 2,360 lbs of payload. The XD is a different chassis length from the regular Titan, so its frame-mounted and bed parts are listed separately.
Titan PRO-4X
The 2024 Titan PRO-4X adds an electronic locking rear differential, Bilstein monotube shocks, underbody protection and 275/70R18 all-terrain tires, against 265/70R18 tires on other grades. The PRO-4X name is shared with the Frontier, but the hardware is sized for a different truck, and nothing interchanges. With production over, check that an aftermarket Titan part is still being made before planning a build around it.
How to Match a Part to Your Nissan
Confirm the model (Frontier, Titan or Titan XD), the model year (for the Frontier, 2022-and-later body or earlier), the cab and bed, and whether the truck is a PRO-4X. Those decide bumper, bed, suspension and tire fitment. The figures on this hub come from Nissan's press kits and its own model pages; we don't buy, install or test this gear ourselves. See how we rank.
Sources
- Nissan News — 2027 Nissan Frontier Press Kit — 3.8-liter V6 (310 hp, 281 lb-ft), 9-speed automatic, Canton, Mississippi assembly; grades and cab/bed configurations; wheelbases, overall lengths and bed floor lengths; PRO-4X part-time 4WD (2.717:1 low), locking rear differential, Bilstein shocks, aluminum skid plates, 265/70R17 tires; maximum towing 7,150 lbs and payload 1,590 lbs; PRO-4X Crew Cab towing.
- Nissan News — 2022 Nissan Frontier Press Kit — All-new 2022 design on the previous model's 126.0-in wheelbase and chassis; 9-speed all-new for 2020; 2022 PRO-4X skid plates (one aluminum, three steel).
- Nissan News — 2024 Nissan TITAN Press Kit — 5.6-liter V8 (400 hp, 413 lb-ft), 9-speed, part-time 4WD with 2.717:1 low; PRO-4X locker, Bilstein monotube shocks and 275/70R18 tires; cab, bed and wheelbase configurations; Titan and Titan XD towing and payload.
- Nissan USA — Nissan TITAN (discontinued models page) — 2024 was the final year of production for the Titan and Titan XD.
