Ford F-150 Towing Capacity by Engine

Written & researched by Wren Ashby Truck Fitment Editor

Published Sep 29, 2026

Maximum Towing by Engine

*Ford footnotes these figures as F-150 SuperCrew ratings that require the Max Tow/Haul Package (53T) and the optional Max Tow Axle upgrade. All ratings are “when properly equipped” and vary with cargo, configuration, accessories and passengers.

Why Your Truck’s Number Is Probably Lower

Ford’s towing guide selector tables show how much the rating moves with configuration. A 3.5L EcoBoost with a 3.31 or 3.55 axle, without the Max Tow Axle, sits in the 10,500 to 11,000 lb range depending on cab and wheelbase. A 5.0L V8 with a 3.15 or 3.31 axle lands between 9,100 and 9,600 lb. A 2.7L tops out at 8,400 lb. Every one of those is a genuine F-150 “towing capacity,” which is why advertised maximums and the sticker on a used truck rarely match. The only reliable number is the one matched to your truck’s exact engine, axle code, cab, wheelbase and drive.

Tremor, Raptor and Raptor R

Off-road trims tow less than a Max Tow SuperCrew. Ford’s 2026 towing guide lists the Tremor at up to 10,600 lb with the 3.5L EcoBoost and a 3.73 axle, and at 10,000 to 10,200 lb with the 5.0L V8. The Raptor is rated at 8,200 lb and the Raptor R at 8,700 lb, both on a 4.10 axle. The Raptor uses a five-link coil-spring rear suspension with a Panhard rod, per Ford’s Raptor specifications, and a 4.10 axle; Ford recommends against 5th-wheel towing with it. See Tremor vs Raptor for the full comparison.

What the Tow/Haul Package and Max Tow Axle Add

Ford's towing guide splits the equipment between two items. The Tow/Haul Package (53T) includes an upgraded rear axle ratio (standard on PowerBoost), an electronic locking rear differential and an integrated trailer brake controller. The optional Max Tow Axle adds an upgraded trailer hitch, a 2-inch reinforced receiver rated at 14,000 lb in place of the standard 11,600 lb receiver, and the higher tow rating. The guide lists these as standard on every F-150:

• 7-wire harness with 4- and 7-pin connectors, and the hitch receiver;
• transmission oil cooler, Smart Trailer Tow Connector and Tow/Haul mode;
• trailer sway control and trailer reverse guidance.

Pro Trailer Backup Assist, Pro Trailer Hitch Assist and the 360-degree camera are standard on Lariat and above. Ford states that gas F-150s towing over 11,600 lb, and hybrids towing over 10,800 lb, need both the 53T package and the Max Tow Axle, and warns that the New Vehicle Limited Warranty may be voided if you tow without them.

GVWR, GCWR and GAWR: The Limits Behind the Tow Rating

Ford's tow ratings are calculated with the SAE J2807 method and assume a truck with the required equipment plus a 150-lb driver and a 150-lb passenger. Four ratings on the door-jamb label all apply at once:

Ford's selector tables list GCWR alongside each trailer rating. A 3.5L EcoBoost SuperCrew 4x4 on the 145.4-inch wheelbase with a 3.55 axle, for example, has a 16,800 lb GCWR and a 10,500 lb trailer rating.

Don’t Forget Payload and Tongue Weight

Ford's guide says conventional tongue weight should be 10% of the loaded trailer, and that tongue weight plus passengers and cargo must not push the truck past its GVWR or rear GAWR. Ford's 2026 maximum payloads, for the best-case configuration of each engine:

Worked example: a 9,000 lb trailer puts about 900 lb on the hitch. Add two 150-lb occupants and 300 lb of gear in the bed, and the truck is carrying 1,500 lb before anything else, most of a 3.5L 4x4's best-case 2,175 lb and nearly all of a 2.7L's 1,715 lb. Ford says to check the door-jamb label for your own truck's carrying capacity, which is usually lower than these maximums. Read our F-150 payload capacity guide alongside this one, and use the towing and payload capacity checker for your own numbers.

Hitch and Frontal Area Limits

Ford lists the F-150 hitch receiver at 5,000 lb weight-carrying with 500 lb of tongue load. Weight-distributing, it's rated to 13,500 lb with 1,400 lb of tongue load, a figure that requires the 53T package and Max Tow Axle. Ford's guide says not to exceed 5,000 lb of trailer without a weight-distribution system, so above that you need a weight-distribution hitch. Ford also caps trailer frontal area at 55 square feet for trucks rated 7,700 lb or less, 65 square feet for trucks rated 7,701 lb and up, and 75 square feet for 5th-wheel and gooseneck trailers. Tall travel trailers can hit the frontal-area limit before the weight limit.

Mirrors and Tires for Towing

Ford lists vehicle width with trailer tow mirrors at 105.9 inches versus 95.7 inches with standard mirrors. If your truck lacks factory tow mirrors, see towing mirrors for the F-150. For load-rated replacement tires, check Ford’s factory sizes on our F-150 tire size page. Owner notes on towing setups are on the F-150 owner hub.

How We Sourced This

Every number here comes from Ford’s 2026 F-150 technical specifications (V1.1, 03/31/26), Ford’s 2026 RV and Trailer Towing Guide and its 2024 Raptor specifications. We do not tow or test vehicles ourselves. See how we rank.

Toyota, Chevrolet, GMC, Ford, Jeep and Ram are trademarks of their respective owners. 4x4 & Overlanding is an independent publication and is not affiliated with, sponsored or endorsed by any vehicle manufacturer.
